Oxygen Charging Rig - Therapy Cylinder (4 x Scott ) Charging points & manifold with relief valve
For aircraft oxygen charging
Purpose-built oxygen charging equipment configured for 4 Sabre Elite Therapy Cylinders, supporting organised and efficient aircraft servicing.
- Central charging manifold
- Finger-tight charging connections
- Safety relief valve, PED compliant
ART.NR 800.010.02
Oxygen Charging Rig - Therapy Cylinder (4 x Scott ) Charging points & manifold with relief valve
Purpose-built oxygen charging equipment configured for 4 Sabre Elite Therapy Cylinders, supporting organised and efficient aircraft servicing.
Oxygen Charging Rig - Therapy Cylinder - 4 x Scott
This Semmco oxygen therapy cylinder charging rig is designed for charging or topping up one to four passenger oxygen therapy cylinders in a four-Scott-cylinder configuration.
The cabinet provides containment in the event of a sudden gas release from a cylinder burst disc, allowing released gas to vent through dedicated cabinet openings.
The therapy cylinders are connected to the charging manifold using finger-tight cylinder connections. The charging inlet uses a 1/4 BSP left-hand thread with a sintered filter. The system is designed for a maximum charging pressure of 1,800 psi and incorporates a safety relief valve.
